Folding Door Systems

Versatile bi-fold doors creating seamless transitions between indoor and outdoor spaces.

Folding Door Systems
Folding Door Systems

Our folding door systems offer maximum flexibility for openings that demand both wide access and visual appeal. The bi-fold design allows panels to stack neatly to one or both sides, opening up entire walls to the outdoors. Engineered with heavy-duty hinges and precision hardware, these doors operate smoothly and reliably even in large-span configurations. Perfect for restaurants, event spaces, and luxury residences.

Key Features

Why Choose Our Folding Door Systems

Bi-Fold Design

Panels fold and stack to one or both sides, opening up to 95% of the aperture.

Large Opening Span

Capable of spanning up to 12 meters with multiple panel configurations.

Weather Resistant

Triple-seal gasket system with integrated drainage for superior weather protection.

Space Saving

Compact stacking design requires no additional sliding space unlike traditional sliding doors.

Floor-Level Threshold

Low-profile threshold option for barrier-free access and wheelchair accessibility.

Multi-Point Locking

Comprehensive locking system with multiple engagement points along the panel stack.

Technical Data

Specifications

Frame Material
6063-T5 Aluminum Alloy
Profile Thickness
1.8mm - 2.5mm
Max Configuration
Up to 12 panels (6 + 6)
Max Panel Width
900mm - 1200mm
Max Panel Height
Up to 3500mm
Glazing Options
5mm to 44mm Double Glazing
U-Value
1.8 - 2.6 W/m²K
Sound Reduction
Up to 42 dB
Air Permeability
Class 5 (EN 12207)
Hardware
ROTO / GU Certified
Warranty
10 Years on Profile, 5 Years on Hardware
